Whirlpool Error Codes List: What Every Homeowner Needs to Know

Have you gotten confused when your Whirlpool appliance started flashing blinking lights on its display? Getting closer and trying to understand only might have made you more confused. But don’t worry, this is not surprising for your Whirlpool appliance. These flashing secret codes are Whirlpool error codes. Although these codes may look like escape room puzzles, they are easy to understand and valuable information that can help you solve your appliance’s problems quickly.

Understanding these error codes is not just about convenience, it is also about maintaining your appliances and knowing when these appliance issues are a DIY project and when you need expert help. But every DIY project needs a good guide. Consider this blog as a guide that will provide you with the right knowledge that will save you time, money and unnecessary service calls for problems you can easily fix by yourself.

Understanding Error Codes

The purpose of error codes is simple – it’s your appliance’s way of telling you what’s not working right. With the help of the code, it will tell you about the exact problem, and where it is happening. All you need to know is how to read the code and fix the problem. Not all problems need professional help. Some of these issues can be solved at home with the right set of instructions.

One of the best things about Whirlpool error codes is that they are quite specific. They would not leave you to do the guesswork. Rather, these codes will tell you the exact problem so that you can get to it faster and resolve it before it turns into a bigger problem.

Whirlpool Washing Machine Error Codes

F20 or F21: Your Washer’s Saying it’s Having Trouble Filling with Water

First check: Are your washing machine’s water valves fully open?
If not, then look for kinked or twisted water hoses.
Along with these, make sure that the water pressure is good.

F22 or F23: Door Lock Problems

The washing machine door might not be shut properly. Always check the door before running the cycle.
The lock mechanism could be stuck.
Try closing the door firmly and restarting the washing machine.

Sud or Sd: Too Many Suds in the Machine

This error code usually shows up when you’ve used too much detergent.
This can also happen with a regular dish soap (don’t worry, we’ve all been there!)
To fix this, you should run an extra rinse cycle.
To make sure this doesn’t happen regularly, use HE detergent and follow the instructions provided for your Whirlpool washing machine.

Whirlpool Dishwasher Error Codes

F1-E1: Flood Protection Triggered

If this shows up then check for kinks in the drain hose.
There also can be blockages in the drain. Remove them.
Sometimes this error code shows up because the drain hose is not properly installed. Check everything related to the drain hose.

F2-E2: Heating Element Issues

This error code shows up when the water is not heated properly.
Check your home’s water heater temperature.
There are also possibilities of mineral buildup on the heating element.
You can also run a simple vinegar wash cycle.

F5-E3: Water Not Draining

This is sometimes caused by something very simple.
Check if there are any food particles in the filter basket, if there are, then clear them out.
Look if there are kinks in the drain hose.
If you have your garbage disposal connected, then make sure it is empty.

F6-E3: Not Filling With Water

Check if the water is turned on.
Look if the water supply lines are kinked.
Check if the float is stuck (the plastic piece in the bottom that moves up and down).
Clean the water inlet screen (located where the water line connects).
If the water pressure is low throughout your house, then this can happen.

Whirlpool Dryer Error Codes

F01: Main Control Board Issues

The most common cause could be an electrical glitch or board failure.
First things first, unplug the dryer for 5 minutes, then plug it back in.
If the code returns after 2-3 loads, the control board might need replacing.

AF or F08: Airflow Problems

This usually means your dryer’s having trouble breathing.
Check the lint filter – even if you think it’s clean, wash it with soap and water.
Inspect your vent hose from the dryer to the wall.
Look for the obvious, i.e., crushed vent hose, lint buildup, or things stuck in the vent.
You can also use a vacuum with a long attachment to clean deep in the vent.

F03: Temperature Sensor Problem

Your dryer’s having trouble measuring heat levels.
Check if clothes are taking longer than usual to dry.
Look for blocked air vents or crushed vent hoses.
If everything is clear but the clothes are still damp, the sensor might need replacing.

F05: Blown Thermal Fuse

This is a safety feature that prevents overheating.
Check if there is a blocked venting first.
If the venting is clear, then you would have to replace the fuse.

PF: Power Failure

This simply means that your dryer has lost power.
This can happen if there is a power outage. Check if other appliances are working.
Look for tripped circuit breakers.
It will clear itself once it is reconnected to power.

Whirlpool Refrigerator Error Codes

PO or PF: Power Outage Alert

This Whirlpool error code usually tells you that there is a power disturbance.
Check if the food is still cold.
If the temperature is normal, simply press any button to clear the code.

Sf or EF: Shopping Mode/ Showroom Mode

This means that your fridge is actually not cooling.
This mode is used when the fridge is kept in the store’s display.
You can easily exit this error code by holding the lock and light buttons for 3 seconds.

5-d: Door Open Too Long

There could be something stuck that is preventing the door from closing.
Check and move the items that are sticking out of the shelves.
Make sure that the door seal is not blocked or dirty.

Er or FS: Failed Freeze Sensor

This error indicates that the temperature sensor might be malfunctioning.
Check if the freezer is actually cold.
If the temperature is not stable, then you would need to call a professional.

Whirlpool Oven Error Codes

F1: Failed Electronic Control Board

This usually means that there is an issue with the main control system.
You should try resetting by cutting power for 1 minute.
If it still continues, then you might need a new control board.

F2: Oven Temperature Too High

This Whirlpool error code indicates that your oven is detecting excessive heat.
Switch off the oven, and let it cool completely before restarting.
Along with this, check if the cooling fan is working properly.

F3 or F4: Temperature Sensor Problem

This error code means that the temperature readings are off.
This might end up affecting cooking performance.
When this error code shows up, it usually needs a new temperature sensor.

F5: Door Lock Problem

This Whirlpool error code mostly shows up during the self-cleaning cycle.
Just check if there is anything that is blocking the door.
Clean the door and make sure the door closes completely.

EOC: End of Cycle

Most of the time, it is identified as an error code, but it is actually not an error.
It is just telling you that cooking is complete.
You can press any button to clear.

When Should You Call a Professional?

Most of the Whirlpool error codes tell you about the issues that are easy DIY projects. But sometimes, these easily fixable issues also need expert help.

Some of the instances where you should consider calling for help:

The error code continues to blink in the display after you have tried the basic fixes.
You hear unusual noises like grinding, squealing, or thumping.
There’s a smell of burning or electrical issues.
You notice water leaking or pooling around the appliance.
Multiple error codes appear at once.
Your appliance won’t turn on or off properly.
You have tried fixing but don’t feel confident about more complicated repairs.
The appliance is still under warranty.

Preventing Future Error Codes

You must have heard the saying – prevention is better than cure. It really is true, even in the case of your appliances! There are some ways you can keep those Whirlpool error codes far away:

Regular Maintenance:

Mark your calendar for monthly appliance check-ups.
Clean filters, vents, and seals regularly.
Check hoses and connections for wear and tear.
Keep your appliance’s surroundings clean and dust-free.

Smart Usage Habits:

Follow the manufacturer’s loading guidelines.
Use appropriate cleaning products (yes, that means no regular dish soap in the washing machine!)
Don’t ignore small issues – they can cause bigger problems.
Keep your user manuals in an easily accessible place.
Take photos of your most common error codes and their solutions.

Professional Maintenance:

Consider annual professional check-ups for heavily used appliances.
Keep a reliable repair service number handy.
Document any repairs or maintenance for future references.

Conclusion

Understanding these Whirlpool error codes is no rocket science. You just need to be able to read the code correctly, understand what it means, and fix the issues. And Voila! Your appliance will be back to working in their perfect condition. Although, at any cost, don’t ignore these error codes. Remember – these codes are your appliance’s way of telling you that something is wrong. They will help you maintain your appliances in a better way. Knowing these codes is the first step toward solving the problem. Bookmark this guide and get to know your appliance in a much better way! And if you need professional help, then simply call Barton Appliance Repair!
